Description
From single to Dual! Depending on budget, application and carrier vehicle the sweeper is configured from the modular system. From the basic machine without a collection container through to the comfortable „Dual“ version with the full range of equipment. Retrofitting at a later date is no problem. The dual version is only available for front mounting.
-
Attachment System Types
Three point linkage for tractor mounting front/rear, mechanic swivel device (reinforced);Three point front with roller levelling (absolutely necessary for collection container Dual from working width 2300 mm)Double three point linkage (front/rear) for tractor mounting with infinitely variable control arm Cat. I and II(not be used in conjunction with collection container Dual)Special three point linkage Cat. I for compact tractor, mechanic swivel device;Special three point linkage Cat. 0, height-adjustable;Forklift attachment with roller levelling system (no swivelling);Forklift truck attachment mech. “swivelling” with roller levelling (absolutely necessary for collection container Dual)Quick change adaptor with roller levelling system, mechanic swivel device;Adapter plate with pivoting balance for yard and small loaders, European standard (Three point linkage is necessary);Adaptor from three-point linkage to weiste - Cat I/II (Three point linkage is necessary);Combi attachement forklift and tractor front;Combi plate Cat. II front;Unimog-truck lift attachment for existing winter service plate
-
Health and Safety
Bema Sweepers UK & Ireland ensures that all applicable products are compliant with British/European standards and come with a CE/UKCA mark.
-
Warranty
Bema Sweepers UK & Ireland offer a 12 (twelve) month warranty on all new products effective from the date of despatch from Bema UK & Ireland which covers against faulty materials and workmanship. The warranty is exclusively to the supplying agent. The warranty is on condition that the fault is reported immediately to the agent, and that the faulty component/ part is made available to Bema UK & Ireland via the agent. Replaced parts carry a 90-day warranty. Bema UK & Ireland’s warranty does not cover faults caused by inadequate maintenance, improper use, modification or incorrect installation. Bema UK & Ireland warranty does not cover wear and tear. Within the warranty period, testing or fault diagnosis at the request of the agent will be carried out without charge to the agent if the defects are established to be manufactures fault, otherwise the purchaser is liable for all costs. Warranty does not cover malicious or accidental damage.
-
Video
bema 20 / bema 20 Dual
SWEEPERS BUILT FROM A MODULAR KIT.Series 20 with main brush Ø 520 mm
Spare Parts
Do you want spare parts for this product?Specification
Working Width (mm)
1250 | 1550 | 1850 | 2300
Brush Speed
Recommended 120 bis max. 160 U/min
Weight for Base Model (kg)
130, 150, 170,190
Application
Free sweeping | Sweeping & taking up dirt | Removal of weeds
Carrier Vehicle
Forklift | Yard loader | Compact loader | Tractor (front) | Tractor (rear)
Collection Container Volume (L)
Single: 135, 165, 195, 245. Dual: 148, 182, 220, 270
Minimum Hydraulic Power of the Carrier Vehicle (L/min)
20, 25, 30, 30
Water Spray Unit (optional)
100/240 l water tank, tank filter and 12/24 Volt pressure pump(direct injection of water into the main brush and rotary side brushes)
Wheels
Ø 200 x 50 mm (height-adjustable / Dual version not height-adjustable);3rd support wheel in heavy duty version;optional completeley heavy duty wheels
Drive
Hydraulic drive, powerful Gerotormotor with drive shaft Ø 32 mm (heavy series, industrial quality);optional mechanical drive incl. drive shaft
Other Equipment (optional)
Hydraulic swivel device (20° to the left/right);bema Control (control unit) incl. wireless remote controller (from 3 functions available);
Main Brush
Ø 520 mm;PPN or snow brush PPN;special equipment: steel/PPN mixture brush, steel flat wire/PPN mixture brush, bema weed brush.Stepless spindel adjustment of the main brush (standard component in Dual version)
Rotary Side Brushes (optional)
Ø 600 mm;hydraulic drive incl. bema SideControl (comfort operation, combines 3-way valve and speed controller);rotary side brushes are available for the right and/or left side.Selectable brushes: PPN, steel/PPN, steel flat wire/PPN, steel flat wire, weed brush
