Description
Whether on playgrounds, sports fields, parks, leisure areas or cycle paths and pavements the bema Kommunal 580 Dual provides impressive performance with simple handling especially for municipal carrier vehicles. The sweeper is universally usable: from the cleaning of light and coarse dirt up to sweeping snow in winter service and removal of annoying weeds.
-
Attachment System Types
Light excavation for vehicles with fixed attachment plate, incl. 3-point with hydraulic lifting;Attachment systems for yard and wheel loaders up to 0,4 m³ bucket capacity with roller levelling system;Attachment for municipal tractor, triangle/three point attachment Cat. 0-II;Attachment for municipal vehicles;
-
Health and Safety
Bema Sweepers UK & Ireland ensures that all applicable products are compliant with British/European standards and come with a CE/UKCA mark.
-
Warranty
Bema Sweepers UK & Ireland offer a 12 (twelve) month warranty on all new products effective from the date of despatch from Bema UK & Ireland which covers against faulty materials and workmanship. The warranty is exclusively to the supplying agent. The warranty is on condition that the fault is reported immediately to the agent, and that the faulty component/ part is made available to Bema UK & Ireland via the agent. Replaced parts carry a 90-day warranty. Bema UK & Ireland’s warranty does not cover faults caused by inadequate maintenance, improper use, modification or incorrect installation. Bema UK & Ireland warranty does not cover wear and tear. Within the warranty period, testing or fault diagnosis at the request of the agent will be carried out without charge to the agent if the defects are established to be manufactures fault, otherwise the purchaser is liable for all costs. Warranty does not cover malicious or accidental damage.
-
Video
Amenity and Groundscare Sweepers, Weed Removal
bema Kommunal 580 Dual
MULTIFUNCTIONAL DEPLOYMENT.Main brush Ø 580 mm with different trims
Spare Parts
Do you want spare parts for this product?Specification
Working Width (mm)
1250 | 1400 | 1550 | 1700 | 1850 | 2050
Brush Speed
Recommended 120 to max. 250 rpm
Weight for Base Model (kg)
157, 162, 167, 172, 177, 181
Application
Free sweeping | Sweeping & taking up dirt | Removal of weeds
Carrier Vehicle
Yard loader | Municipal vehicles | Compact tractor (front) | Tractor (front)
Collection Container Volume (L)
148, 165, 182, 202, 220, 242
Minimum Hydraulic Power of the Carrier Vehicle (L/min)
20, 20, 25, 25, 30, 35
Water Spray Unit (optional)
Direct injection of water into the main brush and rotary side brushes;100 l / 200 l water tank, tank filter and 12 V pressure pump;240 l water tank - rear attachment;
Wheels
Heavy-load wheels Ø 200 x 50 mm;optional super-elastic wheels Ø 200 x 80 mm
Drive
Your choice: mechanical drive incl. drive shaft (the incline of the drive can be adjusted) orhydraulic drive via powerful Gerotormotor with drive shaft Ø 25 mm (heavy series);
Other Equipment (optional)
Hydraulic swivel device (20° to the left/right);bema PowerPack (hydraulic power unit);bema Control (control unit) incl. wireless remote controller (from 3 functions available);
Main Brush
Ø 580 mm;PPN or snow brush PPN.Optional: steel/PPN, steel flat wire/PPN, bema Weed brush (Ø 510/560 mm);easy change of the main brush
Rotary Side Brushes (optional)
Ø 600 mm;hydraulic drive incl. bema SideControl (comfort operation, combines 3-way valve and speed controller);rotary side brushes are available for the right and/or left side.Selectable brushes: PPN, steel/PPN, steel flat wire/PPN, steel flat wire, weed brush
